RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB

Product Categories

RJ45 Ethernet Connector [57]
RJ45 Shielded Connector [64]
RJ45 Multiple Port Connectors [3]
RJ45 Single Port [17]
Cat6 RJ45 Connector [20]
RJ45 With Transformer [196]
RJ11 Jack [39]
RJ45 Without Transformer [97]
RJ45 1X1 21.3mm TAB-DOWN [12]
RJ45 1X1 21.3mm TAB-UP [10]
RJ45 SMD [36]
RJ45 1X1 25.4mm TAB-UP [10]
RJ45 Modular Jack [37]
RJ45 1X1 33mm TAB-UP [7]
RJ45 Female Jack [11]
180 1x1 Angle Vertical /Top Entry [21]
RJ45 Lan Jack [40]
RJ45 1X1 TAB-DOWN / UP [6]
RJ45 Magnetics [26]
2 Port RJ45 [86]
RJ45 1X2 TAB-DOWN / UP [16]
RJ45 1X4 TAB-DOWN / UP [15]
RJ45 PCB Connector [22]
10 Pin RJ45 Connector [11]
RJ45+Single/Dual USB [14]
RJ45 2X1 [17]
RJ45 2X2 [7]
RJ45 2X4 [5]
Isolated Transformers [3]
RJ45 2X8 [1]
SFP Connector RJ45 [11]
Connector Wire Harness [10]
RJ45 2.5G [11]
RJ45 5G [2]
TF SIM CONNECTOR [33]
RJ45 10G [4]
52 Series [35]
53 Series [8]
55 Series [15]
56 Series [57]
57 Series [6]
59 Series [40]
60S Series [3]
RJ45+ Single/Double USB [6]
SMD(10/100/1000M Base-T ; 2 5G/5G/10G Base-T ) Network Transformer Series [72]
DIP(10/100/1000M Base-T ; 2 5G/5G/10G Base-T ) Network Transformer Series [16]

Keyouda Electronic Technology Co.,ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Model Number : KRJ-037NL

Place of Origin : Guangdong, China

MOQ : 1

Price : $0.54-0.70

Type : RJ45

Packaging : DIP

Gender : Female

Housing Material : PBT BLACK

LED Option : Yellow&Green

Latch : Up

Number of Ports : 1

Number of Contacts : 8

PCB Mount Angle : SIDE ENTRY

Mount Style : Through Hole

Performance Speed : 10/100/1000/10G BASE-T

Port Configuration : Single

Jack Configuration : 1 x 1

Terminals per Port : 8

Shield Material : Copper Alloy preplated with Nickel

Contact Now

Product Description

Factory Direct Supply: Single Port, 100Mbps, LED - Equipped & Shielded RJ45 Transformer for Computer Connectors

Part Number	KRJ-037NL	Brand	DGKYD/OEM/ODM
Place of Origin	Guangdong of China	Certification	ISO16949/ISO9001/ISO14001/CE /UL/FCC/Reach/RoHS
Product Type	Connector-Modular	Connector Style	Jack
Jack Type	RJ45	Connector Type	Modular Jack
Latch Style	Standard	Latch	Up
Filter	With Filter	LED Option	With LED
LED Color	Yellow/Green	Panel Stops	With/Without Panel Stops
Shielded	Yes	Applies To	Printed Circuit Board
Performance Speed	10/100/1000/10G BASE-T	Grounding Options	Panel Ground and PCB Ground
Port Configuration	Single	Number of Positions	8
Jack Configuration	1 x 1	Terminals per Port	8
Shield Material	Copper Alloy preplated with Nickel	PCB Mounting Orientation	Side Entry (Right Angle)
Contact Mating Area Plating Material	Gold 6u/15u/30u/50u	Contact Base Material	Phosphor Bronze
Solder Tail Contact Plating Material	Tin-Lead over Nickel	PCB Mounting Style	Through Hole
Termination Method to PC Board	Through Hole-Press-Fit	Board Lock	With/Without Board Lock
Housing Material	PBT Polyester	Housing Color	Black
Housing Material Temperature	Standard	UL Flammability Rating	UL 94V-0

RJ45 single port connector 100Mbps
