100Mb megabit Magnetic connector 8P8C RJ45 with Transformer for Net Bridge

Name: 100Mb megabit Magnetic connector 8P8C RJ45 with Transformer for Net Bridge
Brand: DGKYD
Price: 1 USD

Quality 100Mb megabit Magnetic connector 8P8C RJ45 with Transformer for Net Bridge for sale

Place of Origin : DongGuan of China

Brand Name : DGKYD

Certification : RoHS/CE/UL/FCC/CE/ISO9001/ISO14001

MOQ : 1 piece

Packaging Details : Tray in Carton

Delivery Time : 10 days

Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram

Supply Ability : 100K pcs/day

Model Number : KRJ-141SHGYNL

Price : Please contact us to get the latest price.

Product Name : RJ45 with Transformer

Type : RJ45 Female

Housing : Phenolic, PBT Black (UL94V-0)

Plastic core : Glass fiber filler PBT Black(UL94V-0),ROHS

Shield RJ45 : yes

No.Port : single port

Contact Now

Magnetic 8P8C RJ45 with Transformer for Net Bridge , Metal Shell

Part Number	KRJ-141SHGYNL	Brand	DGKYD/OEM/ODM
Product Type	Connector-Modular	Connector Style	Jack
Jack Type	RJ45	Connector Type	Modular Jack
Latch Style	Standard	Latch	Down
Filter	With Filter	LED Option	G/YLED
Shielded	Yes	Applies To	Printed Circuit Board
Performance Speed	10/100 BASE-TX	Grounding Options	Panel Ground and PCB Ground
Port Configuration	Single	Number of Positions	8
Jack Configuration	1 x 1	Terminals per Port	8
Shield Material	Copper Alloy preplated with Nickel	PCB Mounting Orientation	Side Entry (Right Angle)
Contact Mating Area Plating Material	Gold 6u/15u/30u/50u	Contact Base Material	Phosphor Bronze
Solder Tail Contact Plating Material	Tin-Lead over Nickel	PCB Mounting Style	Through Hole
Housing Material	PBT Polyester	Housing Color	Black
Operation Temperature	-40℃ to +85℃	UL Flammability Rating	UL 94V-0

100Mb megabit Magnetic connector 8P8C RJ45 with Transformer for Net Bridge

Note:RJ45 ,in order to keep good touch between gold finger and crystal head,should paint the gold on the surface,there is 6u,15u,30,50u,usually use 6u,according to customer’s request and cost to proceed, gold finger insert and pull life should be 750 times above.

Applications:

• Integrated RJ45 connector main used to :

• 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical transceiver,IP phone,

internet set-top box,internet camera,net bridge,computer,telecommunication,MODEM,HomePNA,DSL／ADSL and so on.
